Product Overview & System Integration
Lub 630-650W monocrystalline hnub ci vaj huam sib luag yog tsim los rau siab - txiaj ntsig txiaj ntsig- nplai thiab kev lag luam EPC cov haujlwm. Kev siv siab -kev ua tau zoo ib nrab- txiav cov hlwb thiab ntau-busbar (MBB) architecture, qhov qauv no txo qis micro{11}} cuam tshuam tawg thiab txo qis kev puas tsuaj thoob plaws busbars. Lub 1500V DC qhov siab tshaj plaws qhov hluav taws xob muaj peev xwm ncaj qha txo qis Qhov Ntsuas Qhov System (BOS) cov nqi los ntawm kev tso cai rau cov hlua ntev dua ib lub inverter. Tsim los rau kev siv dav dav, cov vaj huam sib luag no sib xyaw ua ke nrog cov qauv kab sib chaws - khi hlua iverters, hybrid zog cia teeb, thiab hnyav - lub luag haujlwm tawm - daim phiaj hnub ci cog dej. Raws li cov chaw tsim khoom lag luam, Xiamen Hemao Kev Lag Luam txhawb nqa ncaj qha OEM ntau lawm, muaj tseeb PCB / inverter txuam, thiab kev cai mounting qhov configurations rau taag qaij lossis ib-axis tracker deployments.
Khoom siv & Technical Specifications
| Khoom Specification | Standard Parameter |
| Peak Fais fab tso zis (Pmax) | 630W - 650W |
| Module efficiency siab tshaj | 21.60% |
| Hom Cell | Monocrystalline (Ib nrab-Txiav) |
| Maximum System Voltage | 1500V DC fais fab mov |
| Ua haujlwm kub | -40℃rau +85 degree |
| Kub Coefficient (Pmax) | -0.34% / degree |
| Junction Box | IP68 Rated, 3 Bypass Diodes |
| Cables | 4.0mm² (12AWG), Custom Length |
| Ncej Khoom | Anodized Aluminium Alloy (AL6005-T5) |
| Pem hauv ntej iav | 3.2mm High Transmission, AR Coated Thaum tshav kub kub-Ntxhiab iav |
| Mechanical Load | Cua: 2400Pa / Daus: 5400Pa |
| Tsim Lub Neej & Warranty | 12-Xyoo khoom Warranty, 30-xyoo Linear Power Warranty |
Kev Tswj Xyuas Zoo & Cov Qauv Ntiaj Teb
Txhua 630-650W module tau dhau los ua kev kuaj xyuas lub Hoobkas nruj kom ntseeg tau tias muaj peev xwm ua tau nyiaj txiag rau ntiaj teb EPC integrators. Peb ua 100% ob chav Electro-Luminescence (EL) kuaj- ob qho tib si ua ntej-lamination thiab tom qab-lamination- txhawm rau tshem tawm sab hauv micro- cracks thiab soldering defects. Cov txheej txheem txheej txheem suav nrog Chav Kawm AAA hnub ci simulator flash kuaj kom paub tseeb wattage thiab cov yam ntxwv hluav taws xob. Txhua pawg ua raws li IEC 61215, IEC 61730, CE, thiab RoHS cov ntawv pov thawj. Tsis tas li ntawd, cov modules dhau nruj ntsev pos huab thiab ammonia corrosion resistance tests, kom ruaj khov zog tawm los nyob rau hauv hnyav ntug hiav txwv dej los yog high-humidity ua liaj ua teb ib puag ncig.
Khoom Paub meej
630-650W Mono Solar Vaj Huam Sib Luag Sib Tsoo Daim Duab Engineering(Unit: hli)
Ntev: ± 2mm Dav: ± 2mm
Hluav taws xob Performance Parameters(Nyob rau hauv Standard Test Conditions)
|
Qauv |
GK-1-78HTB-430M |
GK-1-78HTB-435M |
GK-1-78HTB-440M |
GK-1-78HTB-445M |
GK-1-78HTB-450M |
|||||
|
Kev Xeem |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
|
Lub zog siab tshaj plaws (Pmax / W) |
630 |
477 |
635 |
481 |
640 |
484 |
645 |
488 |
650 |
492 |
|
Qhib -Circuit Voltage (Voc/V) |
56.95 |
54.05 |
57.12 |
54.19 |
57.29 |
54.30 |
57.47 |
54.39 |
57.63 |
54.48 |
|
Peak fais fab mov (Vmp / V) |
13.89 |
11.18 |
13.95 |
11.23 |
14.01 |
11.29 |
14.06 |
11.33 |
14.11 |
11.38 |
|
Luv -Circuit Current (Isc/A) |
47.60 |
45.14 |
47.75 |
45.26 |
47.90 |
45.45 |
48.06 |
45.58 |
48.22 |
45.72 |
|
Peak zog tam sim no (Imp/A) |
13.25 |
10.57 |
13.31 |
10.62 |
13.37 |
10.66 |
13.42 |
10.71 |
13.48 |
10.76 |
|
Module Conversion Efficiency (%) |
22.5 |
22.7 |
22.9 |
23.1 |
23.3 |
|||||
|
|
||||||||||||
1. STC (Standard Test Conditions): Irradiance 1000 W/m², cell kub 25 degree, spectral tis AM1.5
2. NOCT (Nominal Operating Cell Temperature): Irradiance 800 W/m², ambient kub 20 degree, spectral tis AM1.5, cua ceev 1 m/s
Load Capacity
| Maximum Static Load (Pem hauv ntej) | 5400 ua | |||
| Maximum Static Load (Rov qab) | 2400 Nws | |||
| Hail Test Passed | Txoj kab uas hla 25mm, cuam tshuam ceev 23m / s |
Ntim & Logistics Safety
Peb siv zog, xa tawm - qib ntim engineered rau thoob ntiaj teb dej hiav txwv freight. Modules tau ntim vertically nyob rau hauv portrait orientation nyob rau hauv reinforced ob -corrugated cartons, ruaj rau fumigated ntoo pallets. Txhua lub pallet yog qhwv nrog ntau- txheej hnyav- lub luag haujlwm shrink zaj duab xis thiab ntxiv dag zog nrog kev lag luam steel banding. Corner protectors thiab spacer blocks yog muab tso rau ntawm modules los tiv thaiv kev sib txhuam thiab iav tawg thaum lub sij hawm kev thauj mus los. Thawv thauj khoom yog ua lej ua kom zoo tshaj plaws kom siv tau qhov chaw zoo tshaj plaws thaum ua raws li kev txwv qhov hnyav hnyav, ruaj ntseg koj cov xaj ntau los ntawm peb lub Hoobkas hauv pem teb mus rau qhov project site.
Lub sij hawm xa tuaj
|
Ntim (units) |
1-20000 |
＞20000 |
|
Lub sij hawm xa tuaj (hnub) |
15 |
Sib tham tau |
Delivery Teem caij:Rau kev txiav txim qis dua 20,000 daim, lub sijhawm ua tus qauv yog 15 hnub. Rau qhov ntau tshaj qhov no, peb yuav ua haujlwm kom haum raws li koj xav tau.
Hom Daim Ntawv Thov Scenarios
Hom Daim Ntawv Thov Scenarios
Xaiv txoj kev npaj uas haum koj tshaj plaws.
Kev siv hluav taws xob-Sale Solar Farms
Maximizes av siv thiab LCOE ntawm siab zog ceev thiab 1500V DC hlua integration.
01
Solar Plant Watering Systems
Tsav siab - lub zog hloov pauv zaus tsav (VFD) lub hnub ci twj tso kua mis rau loj - cov dej ua liaj ua teb.
02
C&I Rooftop Installations
Muab lub zog tsim hluav taws xob hnyav nrog qhov ua tau zoo tsawg- lub teeb ua haujlwm thaum kaj ntug thiab tsaus ntuj.
03
Cov chaw nres tsheb Telecom Chaw Taws Teeb & Microgrids
Muab kev ruaj ntseg off-grid tiam muaj peev xwm tswj tau qhov kub thiab txias hloov pauv.
04
FAQ
Q: Yuav ua li cas 630-650W vaj huam sib luag ua ke nrog 1500V hlua inverters hauv kev teeb tsa loj?
A: 1500V DC qhov ntsuas qhov ntsuas txo qis txoj hlua suav thiab qhov sib npaug ntawm qhov system (BOS) tus nqi. Cov vaj huam sib luag no zoo kawg nkaus nrog cov hlua ua lag luam loj, ua haujlwm kom txo qis DC cable poob thiab qhov hluav taws xob poob hauv kev siv hluav taws xob- teev hnub ci ua liaj ua teb lossis siab - muaj peev xwm ua liaj ua teb hnub ci kev teeb tsa.
Q: Dab tsi yog qhov tseeb linear degradation tus nqi lav rau no monocrystalline series?
A: Peb tau lees tias thawj zaug - xyoo lub zog degradation tsawg dua 2.0%, ua raws li qhov siab tshaj 0.55% txhua xyoo degradation. Qhov kev tswj hwm nruj no ua kom koj qhov project khaws cia tsawg kawg 84.8% ntawm nws cov khoom siv hluav taws xob nominal txawm tias tom qab 30 xyoo kev ua haujlwm.
Q: Koj lub Hoobkas puas tuaj yeem muab kev hloov kho batch rau kev siv hluav taws xob - nplai EPC kev yuav khoom?
A: Raws li cov chaw tsim khoom ntawm Tuam Tshoj ncaj qha, peb txhawb nqa tag nrho batch customization. Peb lub Hoobkas tswj kev cai DC cable ntev, tshwj xeeb MC4- sib txuas sib txuas sib txuas, hloov xim xim, thiab laser- kos cov lej lej txhawm rau txhawm rau txhim kho ntau EPC kev yuav khoom, qhov chaw taug qab, thiab kev tswj cov cuab tam mus ntev.
Hu rau Action
Thov ib daim kab xev xaim meej thiab cov lag luam wholesale qhov project quote hauv 24 teev. Xa koj BOQ hnub no kom ruaj ntseg Hoobkas- tus nqi ncaj qha. Batch OEM cov qauv muaj rau kev tshuaj xyuas tam sim thiab kev ntsuas zoo.
